UPRIGHT POST INSTALLATION
12
For the round section:
Attach the uprights to the bottom plate with two (2) screws “Z”,
which you will find in the hardware bag.
Uprights must be installed outside the flanged part of the bottom
plate and into the two notchs of the bottom track.
TOP SEAT INSTALLATION
13
Be sure to have a vertical (plumb) upright before fixing the top seat.
Place the top seat on the upper side of the upright.
Center the top seat between the two uprights and secure with four
(4) screws “Z”.
