Triax TOM 011 User Manual

Mode d’emploi / User manual TOM 011
12 / 18
Mesureur Puissance Optique
Optical Power Meter
TOM 011 – Référence / Part Number: 307967
13. Specifications
MODEL
TOM 011
Wavelength(nm)
800~1700nm
Detector Type
InGaAs
Detector Size
Ø 1.0mm
Measurement Range (dBm)
-50~+30
Uncertainty
±5%
Calibrated Wavelength(nm)
850,1300,1310,1490,1550,1625
Resolution(dB)
0.01
Optical Connector
FC/PC and SC/APC
Power Supply
Alkaline Battery(3 AA 1.5V batteries); AC Adaptor(9V)
Battery Operating Time
140 h with 1.5V Battery(3pcs)
Operating Temperatrue(
ć
)
-10 ~ +60
Storage Temperatrue(
ć
)
-25 ~ +70
Relative Humidity
0 to 95% (non-condensing)
Dimension(mm)
190X100X50
Weight(g)
370
14. Standard Accessories
1. Main unit 1
2. Operation Manual 1
3. Cleaning Swabs 1
4. AC Power Supply Adapter 1
5. Soft Carrying Case 1
6. FC/PC and SC/APC adaptors 1
