Trident RiX-70 DC - Appendix B: System Icons; Icon Descriptions

User Manual
RiX 70 DC
14
Appendix B
Icons
SYMBOL
DESCRIPTION
Device with applied parts of type B. IEC 60601-1 uses the term applied
part to refer to the part of the medical device which comes into physical
contact with the patient in order to carry out its intended function.
The product, at the end of its useful life, can not be thrown in the regular
trash with other wastes and is subject to a separate collection.
Alternating Current
N
Conductor connected to the neutral point
L
Connection point to the Power Line
Grounding
Functional earth connection
ON/OFF
POWER ON
Power OFF
Electric shock risk
Product Reference
Serial Number
Manufacturing date
Manufacturer address
Total Filtration
Monoblock
X RAY Tube
Hand cleaning
