QUERY RANDOM ADDRESS (L) According to DALI
READ MEMORY LOCATION According to DALI
QUERY SHORT ADDRESS According to DALI
5.1.5. Switch
basicDIM DGC has two inputs (T1 and T2) for two external switches. Any number of switches can be connected in parallel to the
inputs (parallel connection of T1 and T2 possible).
Action
Reaction
Short press (<
500 ms)
ON/OFF (a short press activates lighting control, with this the switch like the AUTO key of the BasicDIM remote
control)
Long press (>
500 ms)
Dim up/down
A change in light value deactivates the lighting control temporarily. Lighting control is reactivated if the luminaire
switches on again automatically (when motion is detected) or if it is switched off and on manually.
The function can be edited with the basicDIM DGC Programmer or the masterCONFIGURATOR software (see
"Reference list" at the end of this document).
2 x short press Stores the currently measured light value as new setpoint of the lighting control (luminaire acknowledges by
flashing twice).
Depending on the profile selected, this function can be activated or deactivated. The function can be edited with
the basicDIM DGC Programmer or the masterCONFIGURATOR software (see "Reference list" at the end of this
document).
Different output channels are controlled, depending on the profile selected.
...
I NOTICE
Relay only responds to DALI command GO TO SCENE. Other commands are ignored by the Relay.
