5.1.6. Relais
The relay can be used in four different operating modes:
Symbol
Operating
mode Description
Standby Energy saving mode
If the basicDIM DGC module is switched off, the relay will switch off (after 10 minutes).
If the basicDIM DGC is switched on, the relay will switch on.
Switching: relay in standby mode
Only OFF The relay must be switched on using the momentary-action switch, but is switched off by the presence
detector.
ON/OFF The relay is switched on or off via the presence detector.
Relay output The relay must be switched on and off using the momentary-action switch.
Depending on the profile used, the relay will respond differently. For the 5 main profiles (Individual room, Classroom, Corridor, WC,
Free-standing luminaire) the relay operating modes Standby and OnlyOFF are used. The masterCONFIGURATOR software allows to
enable or disable the relay profiles as well (see "Reference list" at the end of this document).
5.1.7. Presence detector
Depending on the profile used, different operating modes are preprogrammed for the presence detector. These can be changed using
the basicDIM DGC Programmer or the masterCONFIGURATOR software (see "Reference list" at the end of this document).
Symbol
Name Description
ON/OFF The light is switched on and off automatically based on the presence/absence of people.
Only OFF The presence detector just switches the connected luminaires off. The luminaires are switched on manually
via the connected external momentary-action switch or the remote control.
neverOFF If no presence is detected, the sensor dims down to the “second light level” parameter and maintains this
setting.
OFF Presence detector disabled. The light must be switched on and off manually.
