18 19 20 21 22 23 24 25 26 27 28 29 30
18 Loudspeaker Output Right Channel :
The loudspeaker cable can be connected to the two binding posts of the terminal. The
positive output terminal is in the top row, the negative is in the bottom row. Make sure
that no loudspeakers with an impedance of less than 3 Ohm are connected. Never short-
circuit the binding posts in order to avoid damage to your integrated amplifier.
19 Power Connection, Power Switch and Fuse :
Use the supplied high-quality power cord Volt to connect the unit to the power supply.
Pay close attention to the markings (red dot) and be sure that all power plugs of your
system are connected properly by inserting them in the same direction into the AC outlet.
Set the power switch to the on position to supply AC power to the unit. When the fuse
blows, replace it only by a fuse of the same rating. Be sure to unplug the unit before
replacing the fuse.
20 Preamplifier Output :
A preamplifier can be connected to this RCA pair. If required, the output can also be used
as a record output (Record). Information on how to activate the record output is provided
later on in this manual under MODE menu.
CAUTION! If the record output is activated, you must not connect a preamplifier to the
output since there is no volume control on the output.
21 SPLIT RETURN :
The output of an effects unit such as surround decoders, equalisers etc. can be
connected to this RCA pair.
22 SPLIT SEND :
The input of an effects unit such as surround decoders, equalisers etc. can be connected
to this RCA pair.
22 - 28 UNBALANCED INPUTS (Input 2 7) :
The RCA pairs INPUT2 through INPUT7 are the unbalanced inputs. The top row of the
inputs is the left channel and the bottom row for the right stereo channel. These inputs
can be used with all traditional line-level sources such as Tuners, CD Players, Tape
Deck, etc.
Turntables will need a separate phonostage (such as the Trigon Vanguard II or Advance)
to amplifier the signal of the phono cartridge to a level which the Energy can accept.
29 Balanced Input (Input 1) :
This pair of connectors can be used with a source unit which is provided with a line level,
