7
provides more information on the functions of the rotary knob.
10 LED ON :
This LED will light up when the Energy is powered on. (operation display)
11 Input pushbutton < :
Pressing this button will select every next input before adjustment of the previous one.
The display [2] shows what input is currently selected.
12 Input pushbutton > :
Pressing this button will select every next input after adjustment of the previous one. The
display [2] shows what input is currently selected.
13 pushbutton SPLIT :
Pressing this button will turn the effect input on/off. The display above becomes brighter
when the effect input is activated.
14 pushbutton LS-OFF :
Pressing this button will turn the loudspeakers off. This function enables you to listen via
the headphones only. When the loudspeakers are turned back on, they will be set to the
initial volume level saved in the MODE menu instead of being adjusted to the possibly
higher sound level set for your earphones - which could otherwise make for an unpleasant
surprise.
15 pushbutton MUTE :
Pressing this button will turn the volume level to zero. A handy solution to silence music
when a phone call is received. Pressing the MUTE button again will deactivate the MUTE
function and restore the previous volume level.
16 pushbutton MODE :
Pressing this button will engage the MODE menu. This menu enables you to perform a
variety of adjustments, therefore an entire chapter is dedicated to the MODE menu. More
information is provided in chapter 4.
17 pushbutton ON/OFF :
This button is used to switch the unit on or off (Standby). From the off-position, the
standby power supply is still active. Press the on/off switch on the rear panel of the
Energy in order to completely turn off the integrated amplifier.
3.2 Rear Panel Connections
