Trigon Energy - Loudspeaker Output - Left Channel

9
balanced input.
Pin 1 - Ground
Pin 2 - Positive Signal (+).
Pin 3 - Negative Signal (-).
30 Loudspeaker Output 󰾴 Left Channel :
The loudspeaker cable can be connected to the two binding posts of the terminal. The
positive output terminal is in the top row, the negative is in the bottom row. Make sure
that no loudspeakers with an impedance of less than 3 Ohm are connected. Never short-
circuit the binding posts in order to avoid damage to your integrated amplifier.
3.3 Remote Control
The Energy offers an optional IR Remote called the Director.
Director
The Director is a system remote that can control multiple
components. It controls the following functions for the
Energy integrated amplifier.:
- On/Off (Standby) : used to turn the preamp on or off.
- Display On/Off : used to turn the display on or off.. When
switched off, a small dot will be displayed behind the Input
LED [2]. Also when switched off, the display will come on
for a few seconds if the preamp is used in order to show
any changes made.
- Mode Menu : used to engage the MODE-Menu. More
information can be found in Chapter 4.
- Mono/Stereo : used to engage Mono operation. Once
engaged, the Mono LED[5] will light up.
- Input + : each press will select the next input.
- Input 󰾴 : each press will select the previous input.
- Volume +10 : the volume will increase by 10
- Volume -10 : the volume will decrease by 10
- Mute : used to mute the outputs. When engaged, a small
dot will be displayed behind the Mute LED[6].
- Volume + : Increase volume
- Volume 󰾴 : Decrease volume
The buttons used for these functions are described in the User
Manual for the Director remote control.
(The image to the left has the relevant buttons for the
Energy highlighed in bold.)
