SETTING DEVICE ID
The unit has the provision to specify a meter address at site for RS485 port. This address can be set starting from 1 to 255 with a
fixed baud rate of 9600
To set the Device ID, proceed the following instruction:
1) Press key for about 4 to 5 seconds on Run Mode display.
2) The unit will enter into Programming Mode display with the settable parameter, unit ADDRESS such as shown below
.
3) Press key. Immediately, P starts blinking with an interval of one second which shows that the parameter is now
settable. Set the ADDRESS by using keys until the desired value is received and then, press key to
confirm the set value.
4) Now, the unit will reset and return into Run Mode.
NOTE: The above details are mentioned in the Installation & Operation Manual for Trinity NF29 Meter.
CONNECTING MULTIPLE METER
Set Unit Id (Modbus Address) as mentioned on
the TrackSo Device
