TRIOBIKE BOXTER - Handlebar; Adjusting the Stem Angle; Parking Lock; Lock

32
HANDLEBAR
PARKING LOCK
- Using a 6 mm Allen wrench loosen the bolt at the front of the stem.
IMPORTANT: do not loosen the bolts on the side of the stem.
- Grasp the stem of the handlebar and rotate to the desired angle.
- Re-tighten the handlebar bolt at the front of the stem and check the
handlebar is securely attached and cannot move.
- Once you have adjusted the angle of the handlebar check the angle of the cables to be
sure they are facing forward.
LOCK
UNLOCK
- Press the LEFT brake lever IN.
- Rotate the small lever to the left.
- Press the LEFT brake lever IN.
- Rotate the small lever to the right.
ADJUSTING THE STEM ANGLE
33
