TRIOBIKE BOXTER - Mid Drive E-System; Rear Rack Mounted Battery; Front Box Mounted Battery

Triobike mono mid drive features a pedal-assist electric drive system provided by Brose:
PLEASE CAREFULLY READ ITS MANUAL.
- Insert the battery in the specific space in the rear rack, then rotate the key on the battery
case to the right: the battery now is locked.
- Press the button on the rear of the battery pack: all the LED should turn on showing the
charge level, then they should turn off. The system now is active.
IMPORTANT:
- plug the charger ONLY on the connector BELOW to the ON/OFF
button placed on the battery.
- don’t leave the battery charging too much time after the full
charge. When the battery is fully charged disconnect it from the
charger.
REAR RACK MOUNTED BATTERY
39
38
MID DRIVE ESYSTEM
FRONT BOX MOUNTED BATTERY
- Insert the battery in the specific stand placed inside the front box and push it towards the
handlebar. Press the power button on the battery pack. The system now is active.
- To remove the battery, insert the key in the lock and turn it counterclock wise, then
remove the battery pulling it toward the front of the bike.
- To charge the battery, plug the charger magnetic connector in the specific socket. The
LED on the battery will start blinking. When the charge is done all the 5 LEDs are on.
IMPORTANT: don’t leave the battery charging too much time after
the full charge. When the battery is fully charged disconnect it from
the charger.
PLUG
CHARGER
HERE
