Triple S 20D - Disassembling and Cleaning Brushes

16
DAILY MAINTENANCE
DISASSEMBLY OF THE BRUSH
To remove the brushes:
1. Lift the brush base (lever 1).
2. Set the brake (lever 2).
3. Clean the hopper as described on page 13.
4. Remove any strings or debris that may be preventing free brush rotation.
5. Unscrew the wing nut (1).
6. Take off the plate (2).
7. Take off the plugs (3).
8. Remove the brushes and clean.
WARNING: Make sure the key is turned to the OFF position.
