SYMBOLS USED ON THE MACHINE
Symbol for the water valve:
Indicates the solenoid valve switch.
Symbol indicating the raised or lowered position of the brush base:
Indicates the lever for lifting the brush base.
Symbol for the brush:
Indicates the brush motor switch.
Symbol for the vacuum motor:
Indicates the vacuum motor switch.
Symbol indicating the raised or lowered position of the squeegee:
Indicates the squeegee lever position.
Symbol indicating the charge levels of the batteries:
It is necessary to recharge the batteries when the green light begins to blink
Symbol for the brakes:
It is used on top of the emergency and parking brake lever.
Indicates the drain pipe of the recovery tank.
