Tripp Lite B024-DPU08 User Manual

2
• 8- or 16-Port 4K DisplayPort/USB 3.0 KVM Switch
• DisplayPort 1.4 Cables (x2)
• USB 3.0 Cables (x2)
• Audio Cables (x2)
• Firmware Upgrade Cable
• Foot Pads (x4)
• Power Adapter
• Mounting Hardware
• Quick Start Guide
• P580-Series DisplayPort Cables
• UR022-Series USB 2.0 Reversible A/B Cables
• P312-Series 3.5 mm Mini Stereo Audio Cables
• P783-0XX-DP DisplayPort/USB/Audio Custom KVM Cables Kits
• P134-000 DisplayPort to DVI Adapter
Package Contents
Optional Accessories

Tripp Lite B024-DPU08 Specifications

General

Console ports	3.5mm headphone, DisplayPort, USB A
Audio connections	Yes
Headphone outputs	10
DisplayPort version	1.2
DisplayPorts quantity	9
Console USB ports quantity	2
Number of computers controlled	8
Cables included	Audio (3.5mm), DisplayPort, USB Type-A to USB Type-B
Maximum resolution	4096 x 2160 pixels
Input current	1.2 A
Output current	3.33 A
Output voltage	12 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	18.44 W
Product color	Black
Rack capacity	1U
Housing material	Metal
Built-in display	No
Package type	Box
Package depth	324.1 mm
Package width	499.1 mm
Package height	133.1 mm
Package weight	4790 g
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 80 %
Sustainability certificates	CE, REACH, RoHS, WEEE
Country of origin	Taiwan
Master (outer) case width	515 mm
Master (outer) case height	155 mm
Master (outer) case length	328 mm
Master (outer) case weight	5400 g
Harmonized System (HS) code	8471.80.1000
Quantity per master (outer) case	1 pc(s)
Master (outer) case GTIN (EAN/UPC)	10037332263725

Weight and Dimensions

Depth	44 mm
Width	214.3 mm
Height	432.4 mm
Weight	3110 g
