Tripp Lite B024-DPU08 User Manual

7
Operation
Hotkey Setting Mode (HSM)
Hotkey Setting Mode is used to set functions on the switch. Follow the steps below to invoke HSM and perform a hotkey
function.
1. Press and hold down the [Num Lock] key.
2. Press and release the [-] key.
3. Release the [Num Lock] key.
4. Press the hotkey to perform the desired function. Refer to the table below for the function.
HSM Summary Table
Key Function
[Port ID][Enter] Switches the KVM, audio and USB focus directly to the computer that corresponds to that Port
ID (B024-DPU08: 1-8 / B024-DPU16: 1-16).
[Port ID][K][Enter] Switches the KVM and audio focus directly to the computer that corresponds to that Port ID
(B024-DPU08: 1-8 / B024-DPU16: 1-16).
[Port ID][U][Enter] Switches only the USB focus directly to the computer that corresponds to that Port ID
(B024-DPU08: 1-8 / B024-DPU16: 1-16).
Note: This hotkey function works on single-stage installation only.
[A][Enter] Starts Auto Scan. The KVM focus cycles from port to port at the default 5-second interval.
[F1] Sets the port OS to Windows.
[F2] Sets the port OS to Mac.
[F3] Sets the port OS to Sun.
[M] Enables / disables mouse emulation.

Tripp Lite B024-DPU08 Specifications

General

Console ports	3.5mm headphone, DisplayPort, USB A
Audio connections	Yes
Headphone outputs	10
DisplayPort version	1.2
DisplayPorts quantity	9
Console USB ports quantity	2
Number of computers controlled	8
Cables included	Audio (3.5mm), DisplayPort, USB Type-A to USB Type-B
Maximum resolution	4096 x 2160 pixels
Input current	1.2 A
Output current	3.33 A
Output voltage	12 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	18.44 W
Product color	Black
Rack capacity	1U
Housing material	Metal
Built-in display	No
Package type	Box
Package depth	324.1 mm
Package width	499.1 mm
Package height	133.1 mm
Package weight	4790 g
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 80 %
Sustainability certificates	CE, REACH, RoHS, WEEE
Country of origin	Taiwan
Master (outer) case width	515 mm
Master (outer) case height	155 mm
Master (outer) case length	328 mm
Master (outer) case weight	5400 g
Harmonized System (HS) code	8471.80.1000
Quantity per master (outer) case	1 pc(s)
Master (outer) case GTIN (EAN/UPC)	10037332263725

Weight and Dimensions

Depth	44 mm
Width	214.3 mm
Height	432.4 mm
Weight	3110 g
