4
Mounting Instructions
The B126-2A1 and B126-2A0 come with mounting hardware
that allows them to be mounted in a variety of ways. The following
images show the different ways the included mounting brackets
can be attached for different mounting methods. Note: The images
below show a B126-1A1 HDMI over Cat5 Receiver Unit, but the
mounting hardware installation is the same for the B126-2A1
and B126-2A0.
Wall-mount 1 Wall-mount 2
19” Rackmount Pole Mount
13-08-043 93-32D0.indd 4 8/28/2013 2:17:37 PM
