14
Receiver with Repeater Daisy-Chain Installation
Model B127A-111-BTBD and B127A-110-BD
Notes:
• Test to ensure the entire installation works properly before pulling cables
through ceilings/walls
• To achieve maximum distance and performance, use 24 AWG solid wire Cat6
cable. Using stranded wire Cat6 cable or cable with a gauge (AWG) size higher
than 24 AWG will result in shorter extension distance. Higher gauge cabling,
such as 26 AWG, has a more limited transmission capability than lower gauge
cabling. All Tripp Lite N202-Series Cat6 cables are made with 24 AWG solid
wire cabling.
• The installation diagram shows the B127A-111-BDTD and B127A-110-BD
installation.
• The B127A-111-BDTD and B127A-110-BD can be daisy-chained up to 4
levels, each link extending 230 ft. (70 m) for a total of 920 ft. (280 m). This
distance can be extended a total of 1,090 ft. (330 m) by adding a
B127A-010-H signal booster between the transmitter and first receiver in the
daisy-chain installation.
