13
Standard Extender Kit Installation
1. Make sure all equipment in the installation—such as monitors, the
DisplayPort source and the transmitter—is powered OFF.
2. Using a DisplayPort cable, connect the DisplayPort source to the INPUT
port on the local transmitter unit.
3. Optional: Using an HDMI cable (such as Tripp Lite P569-XXX-CERT or
P568-XXX-2A Series cables), connect a local monitor to the LOCALOUT
port on the B127A-1A1-BDBD local transmitter unit.
4. Using Cat6 cable, connect the RJ45 port on the local transmitter unit to
the RJ45 port on the remote receiver unit.
5. Optional: To extend the transmission distance up to 400 ft., connect a
B127A-010-H signal booster (sold separately) between the transmitter
and receiver using Cat6 cable.
Note: In a daisy-chain installation, the B127A-010-H signal booster unit
must be placed between the transmitter and first receiver in the chain or
else the signal booster will not function.
6. Using a DisplayPort cable (such as Tripp Lite P580-Series cables),
connect the remote receiver unit’s DisplayPort output to a monitor.
7. Turn the power on to your connected TVs/monitors.
8. Connect the external power supply to the local transmitter unit and plug
it into an available wall outlet or (optional) Tripp Lite Surge Protector,
Power Distribution Unit (PDU) or Uninterruptible Power Supply (UPS).
The POWER (green) LED on the local transmitter unit will illuminate
to indicate the unit is receiving power from the external power supply.
The POWER (green) LED on the remote receiver unit will illuminate to
indicate the unit is receiving power from the local transmitter unit
through PoC technology.
Note: The external power adapter can be plugged into either the transmitter
or the receiver.
9. Turn on the power to the DisplayPort source.
10. The (orange) RJ45 LED will illuminate on both the local transmitter and
remote receiver units to indicate a signal is being received from the
source to display. The screen should now display on the
connected monitor.
