Mounting Instructions
The B127A-1A1-BDBH, B127A-1A1-BDBD, B127A-110-BD and
B127A-111-BDTD include mounting hardware that allows for a variety
of mounting methods. The following images illustrate how the included
mounting brackets can be attached for different installations.
19” Rack-Mount Pole-Mount
Wall-Mount
Note: The model shown in the below images is for illustrative purposes only. Your
product may vary by model number, size or port orientation. The mounting options
for all over IP units are the same.
