Receiver with Repeater Daisy-Chain Installation
1. Make sure all equipment in the installation – such as TVs, Blu-ray
players and the transmitter – is powered OFF.
2. Connect the DisplayPort source to the INPUT port on the
B127A-111-BDTD local transmitter unit using a DisplayPort cable (such
as Tripp Lite P580-Series cables).
3. Connect a local monitor to the local HDMI port using an HDMI cable
(such as Tripp Lite P569-XXX-CERT or P568-XXX-2A High-Speed HDMI
cables)
4. Optional: To increase the maximum transmission distance, connect a
B127A-010-H signal booster (sold separately) between the transmitter
and receiver using Cat6 cable.
Note: In a daisy-chain installation, the B127A-010-H signal booster
unit must be placed between the transmitter and first receiver in the
chain or the signal booster will not function.
5. Using Cat6 cable, connect one of the RJ45 output ports on the local
unit to the RJ45 input port on the B127A-111-BDTD transceiver unit.
6. Connect a monitor to the DisplayPort output port on the transceiver
unit using a DisplayPort cable (such as Tripp Lite P580-Series
DisplayPort Cables).
7. Connect the external power supply to the local transmitter unit and
plug it into a Tripp Lite surge protector, power distribution unit (PDU) or
uninterruptable power supply (UPS). The green RJ45 LED on the
receiver will illuminate to indicate the unit is receiving power. Up to
four units can be daisy-chained (one transmitter and three transceivers).
To connect additional transceiver units, proceed to step 8. To finish your
installation with a B127A-110-BD unit, proceed to step 12.
8. Using Cat6 cable, connect the RJ45 output port on the
B127A-111-BDTD unit receiver unit to the RJ45 input port on a
B127A-110-BD transceiver unit.
9. Connect a monitor to the DisplayPort output port on the
B127A-110-BD that you just added using a DisplayPort cable
(such as Tripp Lite P580-Series DisplayPort cables).
