17
Receiver with Repeater Daisy-Chain Installation
Standard Extender Kit Installation
10. Connect the external power supply to the B127A-110-BD and
plug it into a Tripp Lite surge protector, power distribution unit (PDU
or uninterruptable power supply (UPS). The green power LED and the
green RJ45 LED’s will illuminate to indicate the unit is receiving power.
11. To add a second B127A-110-BH, repeat steps 8 through 10. To finish
your installation with a B127A-110-BH, proceed to step 12.
12. Using Cat6 cable, connect the RJ45 OUTPUT port on the last
B127A-110-BD to the RJ45 INPUT port.
13. Connect a monitor to the DisplayPort INPUT port on the last
B127A-110-BD using a DisplayPort cable.
14. The green LED on the B127A-110-BD will illuminate to indicate the
unit is receiving power from the previous transceiver. The orange LED
will illuminate to indicate the unit is connected to a powered ON
remote/repeater unit.
15. Turn on the power to the DisplayPort source. The orange RJ45 LED’s on
the local unit will illuminate to indicate a signal is being received from
the source.
16. If necessary, use the Equalization control on the remote/repeater unit(s)
and remote receiver unit to adjust the video image.
17. The maximum number of daisy-chain layers is four for a total distance
of 920 ft., but the distance can be extended to 1,090 ft. when a
B127A-010-H signal booster is used. See the B127A-010-H product
features on tripplite.com for details.
Note: An improper Equalization setting can cause the monitor to not
display the picture at all. Try each Equalization setting until an
acceptable picture is displayed.
