9
Standard Extender Kit Installation
2. Using a DisplayPort cable, connect the DisplayPort source to the
INPUT port on the local transmitter unit.
3. Optional for B127A-1A1-BDBH: Using an HDMI cable (such as
Tripp Lite P569-XXX-CERT or P568-XXX-2A Series cables), connect
a local monitor to the LOCALOUT port on the B127A-1A1-BDBH local
transmitter unit.
4. Using Cat6 cable, connect the RJ45 port on the local transmitter unit
to the RJ45 port on the remote receiver unit.
5. Optional: To extend the transmission distance up to 400 ft., connect a
B127A-010-H signal booster (sold separately) between the transmitter
and receiver using Cat6 cable.
6. Using an HDMI cable (such as Tripp Lite P569-XXX-CERT or
P568-XXX-2A Series cables), connect the remote receiver unit’s HDMI
port to a monitor.
7. Turn the power on to your connected TVs/monitors.
8. Connect the external power supply to the local transmitter unit and
plug it into an available wall outlet or (optional) Tripp Lite Surge
Protector, Power Distribution Unit (PDU) or Uninterruptible Power
Supply (UPS). The POWER (green) LED on the local transmitter unit
will illuminate to indicate the unit is receiving power from the external
power supply. The POWER (green) LED on the remote receiver unit
will illuminate to indicate the unit is receiving power from the local
transmitter unit through PoC technology.
Note: The external power adapter can be plugged into either the transmitter
or receiver unit.
9. Turn on the power to the DisplayPort source.
10. The (orange) RJ45 LED will illuminate on both the local transmitter and
remote receiver units to indicate a signal is being received from the
source to display. The screen should now display on the connected
monitor.
