• NFI-U05 or NFI-U08-1 or NFI-U08-2 10/100 Ethernet Switch
• DIN Rail-Mounting Clip (Preinstalled)
• Wall-Mount Mask (Preinstalled on NFI-U08-1 Only)
• Owner’s Manual
• 5 or 8 auto-negotiable 10/100 Mbps RJ45 ports
• Supports 10/100Base-T, Full Duplex and auto MDI/MDI-X crossover
function
• Simple plug-and-play installation and operation with no configuration
required
• Rugged high-strength case
• Industrial temperature switch models support operating temperature
range of -40°F to 167°F (-40°C to 75°C)
• Easy-to-read LEDs indicate connection and activity status for each port
• Meets the following IEEE standards:
o IEEE 802.3 10Base-T
o IEEE 802.3u 100Base-T
o IEEE 802.3 Auto Negotiation
o IEEE 802.3x Flow Control
• Supports MAC address auto-learning and auto-aging
• Preinstalled durable rail clip mounts firmly to any standard 35 mm DIN
rail*
*Note: Only NFI-U05 and NFI-U08-1 are both DIN and wall mountable
Package Contents
Product Features
