14
Cabling
Connect one end of an RJ45 Ethernet cable (see Optional Accessories)
into the switch’s RJ45 Ethernet port. Connect the other end to a network
device. Cat5e cable or above is recommended.
All ports support Fast Ethernet (10/100Base-T), as well as auto-negotiation
and auto MDI/MDI-X to eliminate the need for crossover cabling.
LED Indicators
PWR (Green)
Illuminated
Power on by Terminal Block PWR
or DC jack
Off
Terminal Block PWR/DC jack fails
or is unavailable
10/100 (Green)
Illuminated Link speed is 100 Mbps
Blinking Data is transmitting/receiving
Off Link speed is 10 Mbps
LNK/ACT (Green)
Illuminated Copper port link-up
Blinking Data is transmitting/receiving
Off Port disconnected or link failed
