Outlet quantity / type Hardwire
INPUT
Recommended
Electrical Service
DC INPUT: Requires 12V DC input source capable of delivering 95A for the required duration (when used at full
continuous capacity - DC requirements increase during Over-Power and Double-Boost operation). For automotive
applications, professional hardwire
Maximum input
amps / watts
DC INPUT: Full continuous load - 95A at 12V DC. AC INPUT: 20 amps at 120V AC with full inverter and charger load
(12A max charger-only / combined input load to support charger and AC output is automatically controllable to
66%-33%-0% based on AC output lo
Input connection
type
DC INPUT: Set of 2 DC bolt-down terminals. AC INPUT: hardwire
Input cord length
details
DC INPUT: User supplies cabling. 4 gauge or larger (see manual). AC INPUT: hardwire
Voltage
compatibility (VAC)
120
Voltage
compatibility (VDC)
12
BATTERY
Expandable battery
runtime
Runtime is expandable with any number of user supplied wet or gel type batteries
DC system voltage
(VDC)
12
Battery Pack
Accessory (optional)
98-121 sealed lead acid battery (optional)
Battery recharge rate 14A / 55A (selectable)
LEDS ALARMS & SWITCHES
Switches 3-position on/off/remote switch enables simple on/off power control plus auto/remote setting that enables distant
on/off control of the inverter system when used in conjunction with APSRM4 accessory (sold separately) in inverter
mode.
Front panel LEDs Set of 6 LEDs offer continuous status information on load percentage (6 levels reported) and battery charge level (7
levels reported). See manual for sequences.
SURGE / NOISE SUPPRESSION
AC suppression
joule rating
600
PHYSICAL
Shipping weight (lbs) 24.9
Shipping weight (kg) 11.3
Cooling method Multi-speed fan
Unit Dimensions
(HWD/in)
7 x 8.75 x 9
Unit Dimensions
(HWD/cm)
17.78 x 22.23 x 22.86
Shipping
Dimensions
(HWD/in)
12.5 x 11 x 10.75
Shipping
Dimensions
(HWD/cm)
31.75 x 27.94 x 27.31
