15
TRISAN S8 Instrument description
Symbols
The Standard applied testing voltage for insulation testing is out of range caused by
faulty appliance insulation, electrical protection devices present or an internal fault
of the tester. (Test a known safe appliance to determine that the tester is or not at
fault)..
If the appliance is too large for a cloak, select probe mode in the utilities menu un-
der the check connect utility. In this mode the test is elongated in duration to probe
all possible suspect surface areas.
The S8 is factory defaulted for inverter, IT, hospital or ship derived power, where
there is no neutral leg. Three wire power network with two phase active with earth.
Battery operation
Earth Appliance Class I
Double Insulation Appliance Class II
↑ Scroll Up
↓
Scroll Down
F1 ↑
Select tests using four buttons or scroll up
F2 ↓
Select for configuration or scroll down
To Next Page
