Triton 2000 Series User Manual

3
GB
Parts List
PARTS LIST
A. Table (1)
B. Front end panel (1)
C. Rear end panel (1)
F. Base channels (2)
E. Bearing channels (2)
I. Rip fence (1)
H. Crosscut fence (1)
L. Slide chassis (1) J. Overhead guard
& guard support (1)
G. Protractor (1)
K. Side guard (2)
N. Rip fence bevel guides (2)
D. Legs (4)
MAIN FASTENER BAG
a. Leg locking pin (4)
b. M8 x 16 bolt (4)
c. M8 flange nut (4)
d. 8mm washer (20)
e. M8 nyloc nut (8)
f. M8 x 50 bolt (8)
g. Push-stick hanger (2)
p. Angled foot (4)
q. Trigger strap (1)
r. Fence hanger (2)
s. Tube spanner (1)
u. Scale pointer
labels (1)
h. M5 nyloc nut (3)
i. M5 x 8 screw (2)
j. M5 x 25 screw (1)
k. Saw locators (4)
l. Clamping knobs (4)
m. M6 x 40 screw (4)
n. M6 flange nut (4)
M. Guided
push-stick
& side
pressure
finger kit
o. Saw alignment cams
