Bewitch
9
remove
View from
rear of backplate
Fig.11
Fig.10
Fig.12
Drill and plug to suit the fixing screws supplied.
(The wall plugs provided are suitable for most brick
walls – use an appropriate masonry drill, but if the
wall is plasterboard or a soft building block, you must
use special wall plugs and an appropriate drill bit).
Screw top fixing screw into position leaving the
base of the screw head protruding 6 mm out
from the wall.
Hook the backplate over the top screw and
fit the bottom fixing screw into position. Do
not fully tighten the screws at this stage, as
the fixing holes are elongated to allow for
out of square adjustment after the plumbing
connections have been completed.
