8
Note: This Triton sander is equipped with a soft start feature for increased
operator safety and comfort in use. Let the machine reach full speed before
bringing it into contact with the workpiece.
5. Push down on to the bottom of the On/Off Sliding Switch, to disengage the
switch and stop the machine
WARNING: Lift the machine off the workpiece before switching off.
WARNING: Always wait until the machine has stopped vibrating completely
before putting it down. Always disconnect from the power supply after use.
Adjusting tool speed
• This Triton sander features variable speed control that enables it to be used
with a variety accessories, to work on a multitude of different materials,
workpieces and objects
WARNING: Never fit any accessories to the Hook and Loop Backing Pad (2) that
are not rated to the maximum no load speed of this device (see ‘Specification’).
1. Slide the Speed Control Dial (12) downwards on to a higher number, to
increase the tool speed
2. Slide the Speed Control Dial upwards on to a lower number, to decrease
the tool speed
Note: This Triton sander features an electronic speed controller that holds the
selected speed constant under load.
• If in doubt about the correct speed setting, suitable for the task at hand,
start with a low speed, examine the results, and adjust to a higher setting if
necessary.
Sanding tips
• Clamp workpieces to the workbench wherever possible. Ensure that
workpieces cannot move during work
• If the tool is connected to a vacuum dust extraction system, switch the
extraction device on before switching on the sander. Switch the sander off
first, then the vacuum system
• Move the machine in a circular motion over the workpiece surface,
applying an even, moderate pressure until you reach the desired surface
finish
WARNING: Excessive pressure does not lead to a faster removal of material;
it will however lead to premature wear of the sanding disc, and may cause
damage to the machine. Both sanding performance and quality depend mainly
on the choice of the correct sanding discs.
• If there are still scratches on your workpiece after sanding, refer to
‘Selecting the right grade of sanding disc’
Sanding metal
WARNING: Some additional precautions have to be taken when sanding metal.
• ALWAYS connect the sander via a suitable RCD
• ALWAYS connect the sander to a suitable workshop dust extraction system
• Clean the tool thoroughly before using it to sand metal
WARNING: Hot metal particles and sparks could ignite residual wood dust.
Always clean the tool THOROUGHLY when switching from sanding wood to
sanding metal, and vice versa.
• A sanding disc that was previously used for sanding metal should not be
used on wood again. Residual metal particles may lead to scratches, and
damage the workpiece surface
Accessories
• A range of accessories, including punched hook and loop sanding discs
with various grit, is available from your Triton stockist. For your own safety,
use only genuine Triton accessories. Spare parts can be purchased from
your Triton dealer or online at www.toolsparesonline.com
Maintenance
WARNING: Always disconnect from the power supply before carrying out any
maintenance/cleaning.
• This tool is manufactured using class leading components and makes
use of the latest in intelligent circuitry that protects the tool and its
components. In normal use it should provide a long working life
General inspection
• Regularly check that all the fixing screws are tight. They may vibrate loose
over time
• Inspect the supply cord of the tool, prior to each use, for damage or wear.
Repairs should be carried out by an authorised Triton service centre. This
advice also applies to extension cords used with this tool
Lubrication
• Lubricate all moving parts with a suitable lubricant spray, at regular
intervals
Cleaning
WARNING: ALWAYS wear protective equipment including eye protection and
gloves when cleaning this tool.
• Keep your tool clean at all times. Dirt and dust will cause internal parts to
wear quickly, and shorten the device’s service life
• Clean the body of your machine with a soft brush, or dry cloth
• Never use caustic agents to clean plastic parts. If dry cleaning is not
sufficient, a mild detergent on a damp cloth is recommended
• Water must never come into contact with the tool
• Ensure the tool is thoroughly dry before using it
• If available, use clean, dry, compressed air to blow through the ventilation
holes (where applicable)
Removal of Dust Extraction Port
Note: If dust extraction operates at reduced capacity, the Dust Extraction Port
(10) may have become blocked. It can be removed for thorough cleaning.
1. Remove the Dust Extraction Port Screw (13) using a suitable Phillips
screwdriver (not included)
2. Pull the Dust Extraction Port out of the gear housing
3. Thoroughly clean the insides of the Dust Extraction Port (the use of
compressed air is recommended)
4. Fit the flat end of the Dust Extraction Port back into the gear housing
5. Reattach the Dust Extraction Port Screw and tighten by hand, using a
suitable Phillips screwdriver
Note: If, after cleaning, dust extraction still does not operate properly, the
Hook and Loop Backing Pad should be removed to clean and inspect the dust
channels through the Hook and Loop Backing Pad (2) and gear housing (see
‘Fitting the backing pad).
Maintaining the backing pad brake
• In free-run mode, the rubber collar, located between the Hook and Loop
Backing Pad (2) and the metal gear housing (see Fig. A), controls the
acceleration of the backing pad, when the tool is switched on, until the
Hook and Loop Backing Pad reaches its maximum speed
• The collar wears down with use, and has to be replaced when the braking/
control performance is reduced (see ‘Fitting the backing pad’ for removal/
replacement)
• Contact your authorised Triton service centre for spare parts or
replacement service
Hook and loop surfaces
• Hook and loop surfaces need to be clean, free of dirt and foreign matter,
such as hair, fibres, sand etc.
• In order to provide adequate adhesion for securing accessories, hook and
loop surfaces must be in good condition
• When used extensively, hooks and loops will become elongated or broken,
and the mechanism cannot provide the required strength of adhesion
anymore
Note: This sander’s hook and loop Hook and Loop Backing Pad is NOT a
warranty item. Replacement backing pads can be obtained as spare parts
through an authorised Triton service centre.
Brushes
• Over time the carbon brushes inside the motor may become worn
532839_Z1MANPRO1_AUS.indd 8 24/02/2015 16:04
