8) MULTI Touch Driver Configuration
MULTI Touch configuration Main Manual
Right click the icon to show the Main Menu of
MULTI Touch configuration.
a) Wireless Setting
For wireless use you need to order MULTI Touch Wireless Upgrade Kit (EAN 8592580092015) which
includes WR HUB with antenna, USB WR Receiver and Power Adaptor. This Wireless kit works only with
MULTI Touch board Series.
b) Calibration
Calibration for MULTI Touch after first time installation or if the projector size and projector’s position has
changed.
Click the flashing cross to calibrate, press ESC to exit. Touch each coordinate accurately. The coordinates will
be moved continually until the calibration is completed.
30 wireless channels are available for selection.
To change channel or pairing your MULTI Touch board,
click “scan“ then the detected sensors will show on the table.
Select the “IWB Name” on the list and click “Pair” to make
pairing for the Receiver and Sensor. It is recommended to
rename the Sensor unit after pairing so as not to mix up with
other sensors installed nearby.
Click “Un-pair” to release channel lock.
Make sure to click “Un-pair” and re-do pairing if Sensor Unit
or Wireless Receiver has been changed.
*IWB = Interactive White Board
