Triumph Rocket 3 GT 2021 - Page 281

253
Oil Tank Cover – Removal
Make sure the motorcycle is stabilised and adequately supported.
A correctly supported motorcycle will help prevent it from falling.
An unstable motorcycle may fall, causing injury to the operator or damage to the
motorcycle.
Perform the following operations:
• Seat - Removal
• Battery - Removal
• Fuel Tank - Removal
• Engine – Removal
• Throttle Body – Removal
• Cylinder Head – Removal
NOTICE
Note the position of the dowels for installation
1. Release the fixings in the sequence shown and remove the oil tank cover. Discard the
gasket.
2. Clean the surfaces of the crankcase and the oil tank cover using a lint free cloth.
Oil Tank Cover Release
Sequence
