Triumph Rocket 3 GT 2021 - Page 493

465
NOTICE
The torsional damper assembly is not to be disassembled. If an item of the torsional
damper requires replacing, the complete torsional damper must be replaced.
Perform the following operations:
• Seat - Removal
• Battery - Removal
• Fuel Tank - Removal
• Engine - Removal
• Throttle Body - Removal
• Output Shaft - Removal
1. Remove the torsional damper and the retaining plate from the output shaft. If
necessary, use a soft faced mallet to gently tap the torsional damper off the output
shaft.
1. Torsional damper
2. Retaining plate
3. Output shaft
