Crankshaft Position Sensor – Removal
Make sure the motorcycle is stabilised and adequately supported.
A correctly supported motorcycle will help prevent it from falling.
An unstable motorcycle may fall, causing injury to the operator or damage to the
motorcycle.
If the crankshaft position sensor needs to be replaced, the alternator stator will also be
replaced as they are one assembly.
Perform the following operations:
• Seat - Removal
• Battery - Removal
• Fuel Tank - Removal
• Plenum - Removal (All Markets Except US) or Plenum - Removal (US Markets
Only)
• Alternator Cover - Removal
Note the routing of the alternator harness and the orientation of the harness guide for
installation.
1. Remove and discard the fixings securing the crankshaft position sensor and the
harness guide to the alternator cover.
