MAINTENANCE AND ADJUSTMENT
141
▼ Install new ECM fasteners to secure
the ECM unit. Tighten to 89 lbf in
(10 Nm).
▼ Reconnect the three connectors to
the ECM unit.
▼ Reconnect the accessory connector.
Secure the accessory connector
cable into the ECM cable clips.
▼ Reconnect the battery, positive (red)
lead first and then the negative
(black) lead.
▼ Tighten the battery terminals to
40 lbf in (4.5 Nm).
▼ Apply a light coat of grease to the
terminals to prevent corrosion.
▼ Cover the positive terminal with the
protective cap.
▼ Reinstall the seat (see page 71).
Speed Twin 1200 and Thruxton RS Only
To install the battery:
▼ Place the battery in the battery
case.
▼ Secure with the battery strap and
make sure the USB port socket is
reinstalled.
▼ Reconnect the battery, positive (red)
lead first and then the negative
(black) lead.
▼ Tighten the battery terminals to
40 lbf in (4.5 Nm).
▼ Apply a light coat of grease to the
terminals to prevent corrosion.
▼ Cover the positive terminal with the
protective cap.
▼ Reinstall the seat (see page 71).
Fuses
Warning
Always replace blown fuses with new
ones of the correct rating (as specified
on the fuse box cover).
Never replace a blown fuse with a fuse
of a different rating.
Use of an incorrect fuse could lead
to an electrical problem, resulting in
motorcycle damage, loss of motorcycle
control and an accident.
Note
A blown fuse is indicated when all of the
systems protected by that fuse become
inoperative. When checking for a blown
fuse, use the table to establish which
fuse has blown.
