GENERAL INFORMATION
52
Tire Pressure Monitoring
System (TPMS) (if equipped)
Warning
The daily check of tire pressures
must not be excluded because of the
installation of the TPMS. Check the tire
pressure when the tires are cold using
an accurate tire pressure gage (see
page 132).
Use of the TPMS system to set
inflation pressures may lead to
incorrect tire pressures leading to loss
of motorcycle control and an accident.
Note
Tire Pressure Monitoring System (TPMS)
is an accessory option only available on
models equipped with cast alloy wheels.
Function
Tire pressure sensors are mounted
to the front and rear wheels. These
sensors measure the air pressure inside
the tire and transmit pressure data to
the instruments. These sensors will not
transmit the data until the motorcycle
is traveling at a speed greater than
12 mph (20 km). Two dashes will be
shown in the display screen until the
tire pressure signal is received.
The Tire Pressure Monitoring System
(TPMS) is an accessory equipped
item and must be installed by your
authorized Triumph dealer.
The TPMS display screen on the
instruments will only be activated when
the system has been installed.
An adhesive label will be installed to the
wheel rim to indicate the position of the
tire pressure sensor which is near the
valve.
Tire Pressure Sensor Serial Number
The serial number for the tire pressure
sensor is printed on a label attached
to the sensor. This number may be
required by your authorized Triumph
dealer for service or diagnostics.
When the tire pressure monitoring
system is being installed to the
motorcycle, make sure that your
authorized Triumph dealer records the
serial numbers of the front and rear tire
pressure sensors in the spaces provided
below.
Front Tire Pressure Sensor
Rear Tire Pressure Sensor
