SPECIFICATIONS
175
Tightening Torques Bonneville T100 and Bonneville T120
Battery Terminals 40 lbf in (4.5 Nm)
ECM Unit Fasteners 89 lbf in (10 Nm)
Chain Adjuster Lock Nuts 15 lbf ft (20 Nm)
Chain Guard 80 lbf in (9 Nm)
Clutch Lever Nut 31 lbf in (3.5 Nm)
Oil Filter 89 lbf in (10 Nm)
Spark Plug 9 lbf ft (12 Nm)
Sump Plug 18 lbf ft (25 Nm)
Rear Wheel Spindle Nut 81 lbf ft (110 Nm)
Fluids and Lubricants Bonneville T100 and Bonneville T120
Bearings and Pivots Grease to NLGI 2 specification
Brake Fluid DOT 4 brake fluid
Coolant Triumph HD4X Hybrid OAT coolant (pre-mixed)
Drive Chain Chain spray suitable for XW-ring chains
Engine Oil
Semi or fully synthetic 10W/40 or 10W/50 motorcycle
engine oil which meets specification API SH (or higher) and
JASO MA, such as Castrol Power 1 Racing 4T 10W-40 (fully
synthetic) engine oil, sold as Castrol Power RS Racing 4T
10W-40 (fully synthetic) in some countries.
