General Information
Instrument Panel Layout
1. Speedometer
2. Tachometer
3. Odometer/Trip meter/Clock
4. Tachometer 'red zone'
5. Right hand turn signal light
6. Engine management malfunction
indicator light
7. High beam indicator light
8. High coolant temperature warning
light
9. Neutral indicator light
10.Low oil pressure warning light
11. Low fuel level indicator light
12.Alarm status indicator light (alarm is
an accessory)
13.Left hand turn signal light
14.ABS warning light (ABS models only)
