4/19
CHAPTER1MAINSPECIFICATIONS
Description Unit TH‐SSL TH‐35 TH‐50 TH‐80 TH‐120 TH‐140 TH‐200 TH‐300
Operating
Weight
kg 152 152 295 375 861 861 1795 2635
lb 335 335 650 827 1898 1898 3957 5809
Weightof
MainBody
Kg 86 86 151 210 471 471 846 1283
lb 190 190 333 463 1038 1038 1865 2828
RequiredOil
Flow
l/min 25~50 25~50 40~70 50~90 80~110 80~110 120~180 180~240
gal/min 6.6~13.2 6.6~13.2 10.5~18.5 13~14 21~29 21~29 32~48 48~63
Operating
Pressure
bar 90~120 90~120 110~140 120~150 150~170 150~170 160~180 160~180
psi 1280~1706 1280~1706 1565~1991 1707~21344 2134~2418 2134~2418 2276~2560 2276~2560
ImpactRate bpm 600~1100 600~1100 550~950 400~800 350~700 350~700 350~500 300~450
Hose
Diameter
inch 1/2” 1/2” 1/2” 1/2” 3/4” 3/4” 1” 11/4”
ToolDiameter
mm 53 53 68 75 100 100 140 155
inch 2.087 2.087 2.677 2.953 3.937 3.937 5.511 6.102
Applicable
CarrierWeight
ton 2.5~4.5 2.5~4.5 4~7 6~9 11~16 11~16 18~26 28~35
Impact
EnergyClass
ft.lbs 350 350 500 1100 3250 3250 4900 6500
