 6/19



CHAPTER3INSTALLATION,DISMANTLING,STORING



3.1 INSTALLATION

Hydraulichammerisconnectedtotheexcavatorwithtwooilhosesandtwopins.



 Lowerdowntheexcavatorarmslowly,alignthepinholes,andfixthepinandpinstopper.Operatethebucketcylinder,so

astofixtheotherpin.



 Removetheend

capsofoilhoses,makesurethehosesclean.Connecttothehammeratoneendandtotheexcavator

pipelineattheotherend.Finally,openuptheStopValveontheexcavatorarm.



3.2 DISMANTLING

ShutofftheStopValveontheexcavatorarm.RemovethetwoOil

Hosesfromexcavatorpipeline.RemovethetwoPinsfrom

hammer shell. Excavator Arm goes up slowly, and then the Hammer will be free. Fasten the End Caps to the hammer and

excavatorpipelinetopreventdirt.



3.3 STORING

IftheHammernotbeusedtemporarily,pleasekeepitwell

asperthefollowinginstructions:

Removethechisel.EmptytheN2chamber,andstrikepistonbacktocylinder.LubricatetheFrontHeadbygrease.



PlaceHammeroncrossties,coveredbyraincoat;orindoorwarehoused.



Ifslowingdowntheengine,itwillbemucheasiertoalignthepinholes.

Afterloosingendcapsofoilhoses,pistoncangobackeasily.

Trojan TH Series User Manual
