INSTALLATION OVERVIEWWARRANTY
MAINTENANCE
OPERATION
27
Re-install
current lamp if
it does not need
replacement. Be
sure to rotate
lamp completely.
Do not touch
glass with bare
hands.
1
2
24
1
2
20
1
2
Ensure
sleeveboltis
fullyrotated
untilpositive
stop.
23
1
2
Ensure
sleeveboltis
fullyrotated
untilpositive
stop.
26
1
2
Ensure
sleeveboltis
fullyrotated
untilpositive
stop.
21
Donottouch
glasswith
barehands.
Insertcurved
endofsleeve
first.Donot
rotatesleeve.
25
WetO-ringwith
waterthenplace
overbottomend
ofsleeve.
29
22
WetO-ring
withwater
thenplace
overtopend
ofsleeve.
28
ForBasicSeries,skipto
Step31.
20
