Trojan VISION 360 - Hardware & Tools List

6
10230 - 6
HARDWARE & TOOLS LIST
INSTRUCTIONS FOR ASSEMBLY
• Before you start to assemble, please check the hardware packaging to make sure all parts are included.
• Basic tools, such as spanners will be provided for assembly.
1. Main Frame
(1 PC)
2. Rear Base
(1 PC)
5. Top Beam
(1 PC)
7. Left Buttery
Arm (1 PC)
8. Right Buttery
Arm (1 PC)
3. Vertical Post
(1 PC)
4. Guide Rod
(2 PCS)
6. Buttery
Extension (1 PC)
9. Seat Cushion
Support (1 PC)
10. Seat Support
Post (1 PC)
11. Leg Extension
(1 PC)
12. Arm Curl Frame
(1 PC)
13. Bench Press
Arm (1 PC)
14. Solid Handle
(2 PCS)
15. Left Adjustable
Plate (1 PC)
16. Right Adjustable
Plate (1 PC)
17. Adjustable Press
Frame (A) (1 PC)
18. Adjustable Press
Frame (B) (1 PC)
19. Foam Rod
(Short) (1 PC)
19. Foam Rod
(Long) (1 PC)
21. Lat Bar
(1 PC)
23. Single Pulley
Bracket (2 PCS)
24. Pulley
Bracket (2 PCS)
25. Intersect Pulley
Bracket (1 PC)
26. Arm Curl
Cushion (2 PCS)
27. Seat Cushion
(1 PC)
28. Backrest
Cushion (1 PC)
22. Curl Bar
(1 PC)
