USER MANUAL TST40E, V15.01 page | 6
Technical changes, misprints and errors are reserved.
2. Overview of the lift
2.1. General description
This two post lift is composed of posts, carriages, lifting arms, cylinders and
motor unit etc. It is driven by an electro-hydraulic system. The gear pump
delivers hydraulic oil to the cylinders and pushes its piston upwards. The
piston drives the chain to raise the carriage and the lifting arms. During the
lifting process, the safety latch will automatically and firmly bite with the safety
teeth block in the posts. Therefore, no slipping will happen in case of the
hydraulic system breaks down.
Safety structure
2.2. Technical specifications
