tronical TronicalTune - Configuration Menu

CALIBRATION MODE / ACCURACY LEVEL / ROBOHEAD DELAY /
RESET / ROBOHEAD SPEED / INTERFERENCE LEVEL
BAT
e B G D A E
MENU
BAT
e B G D A
MENU
BAT
e B G D A
MENU
PUSH “ON“ BUTTON. THE SYSTEM COMES UP WITH THE LAST
COMPLETED TUNING IN MULTISTRING MODE. PUSH “BACK“ BUTTON
TO ENTER TUNING SELECTION MODE. MENU LED IS OFF. TO ENTER
CONFIGURATION MENU PRESS AND HOLD THE “DOWN“ BUTTON
UNTIL MENU LED AND “E“ LIGHTS UP LIGHT BLUE.
PRESS “LEFT/RIGHT“ BUTTON TO SELECT THE DESIRED FUNCTION.
BACK
LEFT / RIGHT
E
E
ENTER
FUNCTION MENU
27WWW.TRONICAL-COMPONENTS.COM
OVERVIEW
CONFIGURATION MENU
ENTER
DOWN
LEFT / RIGHT
ON/BACK
CONFIGURATION MENU OVERVIEW
CALIBRATION MODE
ACCURACY LEVEL
ROBOHEAD DELAY
RESET
ROBOHEAD SPEED
INTERFERENCE LEVEL
E
A
D
G
B
e
