tronical TronicalTune - Firmware Version

BAT
e B G D A E
MENU
PUSH “ON“ BUTTON. THE SYSTEM COMES UP WITH THE LAST COMPLETED
TUNING IN MULTISTRING MODE. PUSH “BACK“ BUTTON TO ENTER
TUNING SELECTION MODE. MENU LED IS OFF.
TO ENTER FUNCTION MENU PRESS AND HOLD “UP“
UNTIL MENU LED LIGHTS UP WHITE. PRESS “LEFT/RIGHT“ BUTTON TO
SELECT “G“LED AND PRESS “ENTER“.
LEDS START FLASHING THREE TIMES, ONE TIME FOR EACH OF THE THREE
FIRMWARE VERSION DIGITS. THE FIRST DIGIT NUMBER IS GREEN, THE
SECOND BLUE AND THIRD RED. EACH COLOR SYMBOLIZES VALUES FROM
16 ACCORDING TO THE DIGITS.
G
BAT
MENU
EADGBe
BAT
MENU
EADGBe
BAT
MENU
EADGBe
ENTER
EXAMPLE: LEDS FLASH THREE TIMES
FLASH: 1 FLASH: 2 FLASH: 3
1 6
0
VERSION:
25
ZERO IS SYMBOLIZED IF ALL LEDS ARE WHITE.
WWW.TRONICAL-COMPONENTS.COM
FIRMWARE VERSION
G
FUNCTION MENU
LEFT / RIGHT
UP
i
