tronical TronicalTune - Robohead Delay

BAT
e B G D A E
MENU
BAT
e B G
MENU
BAT
MENU
PRESS “LEFT“ OR “RIGHT“ TO SELECT DESIRED DELAY LEVEL AND
CONFIRM WITH “ENTER“. ALL STRING LEDS FLASH GREEN TWICE TO
CONFIRM SELECTED DELAY LEVEL HAS BEEN STORED.
PUSH ”BACK” FOR CONFIGURATION MENU.
THE MAX DELAY LEVEL AS SHOWN LEFT WILL DELAY THE START
OF THE ROBOHEADS BY 2,5 SEC. EACH ADDITIONAL LED DECREASES
THE DELAY BY 0,5 SEC.
E
E
A
A
D
D
G
B
B
e
D
LEFT / RIGHT
ENTER
ROBOHEAD SPEED
BACK
low Delay
No Delay
high Delay
(2,5 sec)
EXAMPLE: MAX DELAY
32WWW.TRONICAL-COMPONENTS.COM
ROBOHEAD DELAY
SET THE STARTDELAY OF THE ROBOHEADS.
D
CONFIGURATION MENU
PUSH “ON“ BUTTON. THE SYSTEM COMES UP WITH THE LAST COMPLETED
TUNING IN MULTISTRING MODE. PUSH “BACK“ BUTTON TO ENTER TUNING
SELECTION MODE. MENU LED IS OFF. TO ENTER
CONFIGURATION MENU PRESS AND HOLD THE “DOWN“ BUTTON UNTIL
MENU AND “E“ LED LIGHT UP LIGHT BLUE.
TO ACCESS ROBOHEAD DELAY SELECT “D“LED AND PRESS ”ENTER”.
WHEN YOU CHANGE A TUNING THE ROBOHEADS WILL START
IMMEDIATELY IN ORDER TO CHANGE THE PITCH. WITH THIS
FUNCTION YOU CAN DELAY THE START UP TO 2.5 SECONDS.
ENTER
DOWN
LEFT / RIGHT
ON/BACK
THE DEFAULT IS NO DELAY ALL LEDS ON.
