SCREW OFF THE LOCK NUT AND
MAKE SURE THAT THE RECESS IS AT
AROUND 90 DEGREES TO LONG
ITUDINAL DIRECTION OF THE NECK.
YOU CAN TURN MANUALLY ON THE
KEY OR BY STRING UP MODE PAGE 23
PULL TIGHT ON THE STRING TO GET
PRETENSION AND BEND IT ONE HALF
TURN AROUND THE BOTTOM SIDE OF
THE STRING SHAFT.
MERGE THE STRING UP TROUGH THE
STRING RECES TOWARDS THE THREAD.
BEND THE STRING AROUND THE
SHAFT AS SHOWN IN THE PICTURE
AN SCREW ON THE LOCK NUT
1 2 43
7
HOW TO USE THE STRING SHAFT
GETTING STARTED
WWW.TRONICAL-COMPONENTS.COM
90°
