EN 6
Operating manual – laser distance measuring device BD16
Operation
Inserting the batteries
Insert the supplied batteries before first use.
Notice
Make sure that the surface of the device is dry and the
device is switched off.
Attaching the belt clip and wrist strap (optional)
Info
Please note that the belt clip has to be removed to
change the batteries (see chapter Battery change).
Using the belt clip as end piece
To stabilise the device, you can use the belt clip as an end
piece. In this case, you can shift the reference value to the end
of the end piece.
1. Remove the belt clip if it is mounted.
2. Mount the belt clip as end piece.
3. Press the button for the reference value(9) until the
Reference value end piece indication(22) is displayed.
