Trotec BD21 User Manual

1 EN
Operating manual – laser distance measuring device BD21 / BD26
Table of contents
Notes regarding the operating manual.................................1
Safety .....................................................................................2
Information about the device................................................3
Technical data .......................................................................4
Transport and storage...........................................................5
Operation ...............................................................................5
Fault indications ..................................................................10
Maintenance and repair ......................................................11
Disposal ...............................................................................11
Notes regarding the operating manual
Symbols
Warning of electrical voltage
This symbol indicates dangers to the life and health of
persons due to electrical voltage.
Warning of laser radiation
This symbol indicates dangers to the health of persons
due to laser radiation.
Warning
This signal word indicates a hazard with an average
risk level which, if not avoided, can result in serious
injury or death.
Caution
This signal word indicates a hazard with a low risk
level which, if not avoided, can result in minor or
moderate injury.
Notice
This signal word indicates important information
(e.g. material damage), but does not indicate hazards.
Info
Information marked with this symbol helps you to carry
out your tasks quickly and safely.
Follow the manual
Information marked with this symbol indicates that the
operating manual must be observed.
You can download the current version of the operating manual
and the EU declaration of conformity via the following link:
BD 21
http://hub.trotec.com/?id=40260
BD 26
http://hub.trotec.com/?id=40261
