Trotec BF06 User Manual

4 EN
luxmeter BF06
Display
Lux Fc x10 x100
MAX
8
11
10
12
13
14
9
No. Designation
8 Indication of the measured value x100
9 Indication of the measured value x10
10 Measurement value indication
11 MAXindication
12 Battery status
13 Fcindication (foot candle)
14 Luxindication
Technical data
Parameter Value
Model BF06
Weight 138g
Dimensions
(lengthx widthx
height)
157mmx 56mmx 33mm
Display LCD, monochrome
Measuring range 0.1 to 20lx or 0.1 to 20fc
up to 2000lx or up to 200fc
up to 20klx or up to 2000fc
up to 40klx or up to 4000fc
Accuracy ±5% ±10lx/fc
(<10,000lx/ 1,000fc),
±10% ±10lx/fc
(>10,000lx/ 1,000fc)
Measuring range
resolution
0.1lx/ 0.01fc
Measuring rate 2.5x per second
Operating
temperature
0°C to 40°C at max. 80%RH
(non-condensing)
Operating altitude max. 2000m
Storage temperature -10°C to 60°C
Power supply 1x 9V battery
(battery life approx. 5000 to
8000measurements)
Device switch-off after approx. 17minutes of non-use
Scope of delivery
• 1x Luxmeter BF06
• 1 x 9V battery
• 1x Bag/ holster
• 1x Quick guide
Transport and storage
Note
If you store or transport the device improperly, the
device may be damaged.
Note the information regarding transport and storage of
the device.
Transport
For transporting the device, use the bag included in the scope of
delivery in order to protect the device from external influences.
Storage
When the device is not being used, observe the following
storage conditions:
• dry and protected from frost and heat
• protected from dust and direct sunlight
• with a cover to protect it from invasive dust if necessary
• The storage temperature is the same as the range given in
the Technical data chapter.
• Remove the battery from the device.
