4 EN
moisture indicator BM31
Information about the device
Device description
The dielectric humidity sensor serves the purpose of a quick,
indicative and non-destructive localization of humidity or
moisture distributions.
The measuring device is suited for the preliminary check of the
building materials' readiness for covering for subsequent CM
measurements. The moisture indication allows the localization
of the most significant measuring spots to extract material for
the CM measurement.
A max/minfunction is available for the assessment of the
measurements.
The measuring device comes equipped with a selectable display
illumination.
When not in use, an automatic switch-off saves the battery.
Device depiction
1
2
3
4
No. Designation
1 Sensor
2 Battery compartment with cover
3 Operating elements
4 Display
Operating elements
5
6
7
8
No. Designation
5 Lamp button
6 MEAS button
7 MAX/MINbutton
8 On/off button
Display
9
10
11
12
13
No. Designation
9 MAX indication
10 MIN indication
11 HOLD indication
12 Battery indication
13 Measurement value indication
